74437349015

Würth Elektronik
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-LHMI Nonstandard 0.287Lx0.260W 7.30mmx6.60mm 1.5muH
PDF
/
Inventory: 9666
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Iron Powder

Technical

Operating Temperature -40°C~125°C
Packaging Cut Tape (CT)
Series WE-LHMI
Size / Dimension 0.287Lx0.260W 7.30mmx6.60mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Molded
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 8A
Shielding Shielded
Depth 6.6mm
Current Rating 8A
Frequency 35MHz
Inductance 1.5μH
Test Frequency 100kHz
DC Resistance (DCR) 9mOhm Max
Max DC Current 8A
Frequency - Self Resonant 35MHz
Inductance Frequency - Test 100kHz
Current - Saturation 14.5A
Inductance Tolerance 20%
RMS Current (Irms) 8A
Series Resistance 9MOhm

Dimensions

Height 4.8mm
Height Seated (Max) 0.197 5.00mm
Length 7.3mm
Width 6.6mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
