744373460022
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-LHMI Nonstandard 0.287Lx0.260W 7.30mmx6.60mm 220nH
PDF
/
Buying Options
Total Price: USD $1.71
Unit Price: USD $1.714985
≥1 USD $1.714985
≥10 USD $1.491291
≥100 USD $1.351319
≥500 USD $1.208731
≥1000 USD $1.144631
Inventory: 958
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 6.604mm
Length 7.3mm
Height Seated (Max) 0.118 3.00mm
Height 2.8mm
Technical
Series Resistance 2.8mOhm
RMS Current (Irms) 15A
Inductance Tolerance 30%
Current - Saturation 44A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 149MHz
Max DC Current 15A
DC Resistance (DCR) 2.8mOhm Max
Test Frequency 100kHz
Inductance 220nH
Frequency 149MHz
Current Rating 15A
Depth 6.6mm
Shielding Shielded
Current Rating (Amps) 15A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Molded
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Size / Dimension 0.287Lx0.260W 7.30mmx6.60mm
Series WE-LHMI
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Iron Powder
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
