744373240022
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-LHMI Nonstandard 0.175Lx0.160W 4.45mmx4.06mm 220nH
PDF
/
Buying Options
Total Price: USD $17.37
Unit Price: USD $17.37265
≥1 USD $17.37265
≥10 USD $14.25475
≥100 USD $13.8092
≥500 USD $13.36365
≥1000 USD $12.9181
Inventory: 1076
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 4.06mm
Length 4.45mm
Height Seated (Max) 0.079 2.00mm
Height 1.8mm
Technical
Series Resistance 7.3MOhm
RMS Current (Irms) 9.5A
Inductance Tolerance 30%
Current - Saturation 17A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 195MHz
Max DC Current 9.5A
DC Resistance (DCR) 7.3mOhm Max
Test Frequency 100kHz
Inductance 220nH
Frequency 195MHz
Current Rating 9.5A
Depth 4.06mm
Shielding Shielded
Current Rating (Amps) 9.5A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Molded
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Size / Dimension 0.175Lx0.160W 4.45mmx4.06mm
Series WE-LHMI
Packaging Digi-Reel?
Operating Temperature -40°C~125°C
Physical
Material - Core Iron Powder
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
