7443640680
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-HCF Nonstandard 1.122Lx0.768W 28.50mmx19.50mm 6.8muH
PDF
/
Buying Options
Total Price: USD $16.11
Unit Price: USD $16.10915
≥1 USD $16.10915
≥10 USD $13.2183
≥100 USD $12.80505
≥500 USD $12.3918
≥1000 USD $11.97855
Inventory: 15
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 19.5mm
Length 28.4988mm
Height Seated (Max) 0.728 18.50mm
Height 18.5mm
Technical
Ambient Temperature Range High 75°C
Series Resistance 2.4mOhm
RMS Current (Irms) 30A
Inductance Tolerance 15%
Current - Saturation 55A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 17MHz
Max DC Current 30A
DC Resistance (DCR) 2.4mOhm
Test Frequency 100kHz
Inductance 6.8μH
Current Rating 30A
Shielding Shielded
Current Rating (Amps) 30A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±15%
Size / Dimension 1.122Lx0.768W 28.50mmx19.50mm
Series WE-HCF
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Material - Core Manganese Zinc Ferrite (MnZn)
Supplier Device Package 2818
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 22 Weeks
