7443633300
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-HCF Nonstandard 0.858Lx0.846W 21.80mmx21.50mm 33muH
PDF
/
Buying Options
Total Price: USD $4.15
Unit Price: USD $4.1477
≥1 USD $4.1477
≥10 USD $3.40385
≥100 USD $3.29745
≥500 USD $3.19105
≥1000 USD $3.08465
Inventory: 1149
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 21.5mm
Length 21.8mm
Height Seated (Max) 0.571 14.50mm
Height 14.5mm
Technical
RMS Current (Irms) 12A
Inductance Tolerance 15%
Current - Saturation 11A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 12MHz
Max DC Current 12A
DC Resistance (DCR) 11.4mOhm
Test Frequency 100kHz
Inductance 33μH
Frequency 12MHz
Current Rating 12A
Depth 21mm
Shielding Shielded
Current Rating (Amps) 12A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 11.4Ohm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±15%
Size / Dimension 0.858Lx0.846W 21.80mmx21.50mm
Series WE-HCF
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Manganese Zinc Ferrite (MnZn)
Number of Pins 3
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 22 Weeks
