74435571500

Würth Elektronik
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-HCI Nonstandard 0.720Lx0.717W 18.30mmx18.20mm 15muH
PDF
/
Buying Options
Total Price: USD $5.16
Unit Price: USD $5.1568
≥1 USD $5.1568
≥10 USD $5.0512
≥100 USD $4.4704
Inventory: 1160
Minimum: 1
-
+

Technical Details

Compliance

Ratings AEC-Q200
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 18.2mm
Length 18.3mm
Height Seated (Max) 0.362 9.20mm
Height 9mm

Technical

Series Resistance 9mOhm
RMS Current (Irms) 14A
Inductance Tolerance 20%
Current - Saturation 14A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 14MHz
Max DC Current 14A
DC Resistance (DCR) 9mOhm
Test Frequency 100kHz
Inductance 15μH
Current Rating 14A
Depth 18.2mm
Shielding Shielded
Current Rating (Amps) 14A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 9mOhm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.720Lx0.717W 18.30mmx18.20mm
Series WE-HCI
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Material - Core Metal Composite
Supplier Device Package 1890
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 14 Weeks
