7443320150
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-HCC Nonstandard 0.476Lx0.449W 12.10mmx11.40mm 1.5muH
PDF
/
Buying Options
Total Price: USD $2.31
Unit Price: USD $2.3056
≥1 USD $2.3056
≥10 USD $2.2352
≥100 USD $2.1208
≥500 USD $2.0416
Inventory: 427
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 11.4046mm
Length 12.0904mm
Height Seated (Max) 0.394 10.00mm
Height 9.5mm
Technical
RMS Current (Irms) 19.5A
Inductance Tolerance 20%
Current - Saturation 27A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 92MHz
Max DC Current 19.5A
DC Resistance (DCR) 3.5mOhm Max
Test Frequency 100kHz
Inductance 1.5μH
Current Rating 19.5A
Shielding Shielded
Current Rating (Amps) 19.5A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.476Lx0.449W 12.10mmx11.40mm
Series WE-HCC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
