744323100
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-HCI Nonstandard 0.417Lx0.417W 10.60mmx10.60mm 1muH
PDF
/
Buying Options
Total Price: USD $32.94
Unit Price: USD $32.9441
≥1 USD $32.9441
≥10 USD $27.0313
≥100 USD $26.18675
≥500 USD $25.3422
≥1000 USD $24.4967
Inventory: 5006
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 10.6mm
Length 10.6mm
Height Seated (Max) 0.122 3.10mm
Height 2.8mm
Technical
Series Resistance 4.79Ohm
RMS Current (Irms) 14A
Inductance Tolerance 20%
Current - Saturation 21A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 69MHz
Max DC Current 14A
DC Resistance (DCR) 4.79mOhm
Test Frequency 100kHz
Inductance 1μH
Current Rating 14A
Depth 10.6mm
Shielding Shielded
Current Rating (Amps) 14A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.417Lx0.417W 10.60mmx10.60mm
Series WE-HCI
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C
Physical
Supplier Device Package 1030
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
