744314024
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 240NH 20A 1 MOHM SMD
PDF
/
Buying Options
Total Price: USD $4.7
Unit Price: USD $4.6987
≥1 USD $4.6987
≥10 USD $3.8551
≥100 USD $3.7354
≥500 USD $3.61475
≥1000 USD $3.4941
Inventory: 370
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 7050
Technical
Operating Temperature -40°C~150°C
Packaging Tape & Reel (TR)
Series WE-HCI
Size / Dimension 0.276Lx0.272W 7.00mmx6.90mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Current Rating (Amps) 20A
Shielding Shielded
Inductance 240nH
DC Resistance (DCR) 1mOhm
Frequency - Self Resonant 320MHz
Inductance Frequency - Test 100kHz
Current - Saturation 28A
Inductance Tolerance 20%
Dimensions
Height Seated (Max) 0.197 5.00mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
