744150
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Toroidal Active Bulk fixed air core inductor -40C~105C 25MHz 15mOhm Max 26muH
PDF
/
Buying Options
Total Price: USD $1.8
Unit Price: USD $1.800642
≥1 USD $1.800642
≥10 USD $1.698718
≥100 USD $1.602566
≥500 USD $1.511856
≥1000 USD $1.426284
Inventory: 1280
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Wire
Mounting Type Through Hole
Package / Case Radial, Vertical (Open)
Material - Core Iron Powder
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Series WE-SI
Size / Dimension 1.122Diax0.571W 28.50mmx14.50mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
Type Toroidal
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Current Rating (Amps) 10.3A
Shielding Shielded
Depth 14.5mm
Current Rating 10.3A
Lead Pitch 11.5mm
Inductance 26μH
DC Resistance (DCR) 15mOhm Max
Max DC Current 5A
Frequency - Self Resonant 25MHz
Inductance Frequency - Test 10kHz
Current - Saturation 4A
Series Resistance 15mOhm
Dimensions
Diameter 28.5mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
