744104
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 167UH 1.35A 400 MOHM
PDF
/
Inventory: 5186
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 8.001mm
Technical
Current - Saturation 720mA
Inductance Frequency - Test 10kHz
Frequency - Self Resonant 4.1MHz
DC Resistance (DCR) 400mOhm Max
Test Frequency 10kHz
Inductance 167μH
Current Rating 1.35A
Shielding Unshielded
Current Rating (Amps) 1.35A
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Type Toroidal
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.689Diax0.315W 17.50mmx8.00mm
Series WE-SI
Packaging Bulk
Operating Temperature -40°C~105°C
Physical
Material - Core Ferrite
Package / Case Radial, Vertical (Open)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
