74408943220

Würth Elektronik
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-SPC Nonstandard 0.189Lx0.189W 4.80mmx4.80mm 22muH
PDF
/
Buying Options
Total Price: USD $1.96
Unit Price: USD $1.9624
≥1 USD $1.9624
≥10 USD $1.92896
≥100 USD $1.8568
≥500 USD $1.7864
≥1000 USD $1.64296
Inventory: 5854
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 20 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Ferrite

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-SPC
Size / Dimension 0.189Lx0.189W 4.80mmx4.80mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 1.1A
Shielding Shielded
Depth 4.8mm
Current Rating 1.1A
Inductance 22μH
Test Frequency 100kHz
DC Resistance (DCR) 213mOhm Max
Max DC Current 1.1A
Frequency - Self Resonant 19MHz
Inductance Frequency - Test 100kHz
Current - Saturation 1.4A
Inductance Tolerance 20%
RMS Current (Irms) 1.1A

Dimensions

Height 3.8mm
Height Seated (Max) 0.161 4.10mm
Length 4.8mm
Width 4.8mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
