744052009 image
Favorite
744052009 image
Favorite
RoHS
RoHS RoHS compliant
Package 2323 (5858 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description FIXED IND 9UH 1.25A 110 MOHM SMD
PDF
/
Buying Options
Total Price: USD $1.16
Unit Price: USD $1.156233
≥1 USD $1.156233
≥10 USD $1.09078
≥100 USD $1.029051
≥500 USD $0.970794
≥1000 USD $0.915851
Inventory: 1188
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.079 2.00mm

Technical

Inductance Tolerance 30%
Current - Saturation 1.35A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 40MHz
DC Resistance (DCR) 110mOhm Max
Inductance 9μH
Shielding Shielded
Current Rating (Amps) 1.25A
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Size / Dimension 0.228Lx0.228W 5.80mmx5.80mm
Series WE-TPC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Material - Core Ferrite
Package / Case 2323 (5858 Metric)
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
