744043470
RoHS
RoHS compliant
RoHS compliantPackage 1919 (4848 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 47UH 750MA 280 MOHM
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.8018
≥1 USD $0.8018
≥10 USD $0.65835
≥100 USD $0.63745
≥500 USD $0.6175
≥1000 USD $0.5966
Inventory: 1088
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.118 3.00mm
Technical
Inductance Tolerance 30%
Current - Saturation 500mA
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 10MHz
DC Resistance (DCR) 280mOhm Max
Inductance 47μH
Shielding Shielded
Current Rating (Amps) 750mA
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Size / Dimension 0.189Lx0.189W 4.80mmx4.80mm
Series WE-TPC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Number of Pins 2
Package / Case 1919 (4848 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
