74404064220

Würth Elektronik
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-LQS Nonstandard 0.236Lx0.236W 6.00mmx6.00mm 22muH
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.67165
≥1 USD $0.67165
≥10 USD $0.551
≥100 USD $0.5339
≥500 USD $0.5168
≥1000 USD $0.4997
Inventory: 20162
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 6mm
Length 5.9944mm
Height Seated (Max) 0.177 4.50mm
Height 4.5mm

Technical

RMS Current (Irms) 1.8A
Inductance Tolerance 20%
Current - Saturation 2.2A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 15MHz
Max DC Current 1.8A
DC Resistance (DCR) 89mOhm
Test Frequency 100kHz
Inductance 22μH
Current Rating 1.8A
Shielding Shielded
Current Rating (Amps) 1.8A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.236Lx0.236W 6.00mmx6.00mm
Series WE-LQS
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C

Physical

Material - Core Ferrite
Supplier Device Package 6045
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 13 Weeks
