74404032220
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-LQS Nonstandard 0.118Lx0.118W 3.00mmx3.00mm 22muH
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.30115
≥1 USD $0.30115
≥10 USD $0.247
≥100 USD $0.2394
≥500 USD $0.2318
≥1000 USD $0.2242
Inventory: 1121
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 28 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 3015
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Cut Tape (CT)
Series WE-LQS
Size / Dimension 0.118Lx0.118W 3.00mmx3.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 600mA
Shielding Shielded
Current Rating 600mA
Inductance 22μH
Test Frequency 100kHz
DC Resistance (DCR) 450mOhm
Max DC Current 600mA
Frequency - Self Resonant 19MHz
Inductance Frequency - Test 100kHz
Current - Saturation 600mA
Inductance Tolerance 20%
RMS Current (Irms) 600mA
Dimensions
Height 1.5mm
Height Seated (Max) 0.059 1.50mm
Length 2.9972mm
Width 2.9972mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
