7440329002
RoHS
RoHS compliant
RoHS compliantPackage 1210 (3225 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-LQ 1210 (3225Metric) 0.126Lx0.098W 3.20mmx2.50mm 2.2muH
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.572606
≥1 USD $0.572606
≥10 USD $0.540199
≥100 USD $0.509623
≥500 USD $0.480779
≥1000 USD $0.453561
Inventory: 1138
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 2.4892mm
Length 3.2004mm
Height Seated (Max) 0.067 1.70mm
Height 1.55mm
Technical
RMS Current (Irms) 790mA
Inductance Tolerance 20%
Current - Saturation 1.2A
Inductance Frequency - Test 1MHz
Frequency - Self Resonant 63MHz
Max DC Current 790mA
DC Resistance (DCR) 126mOhm Max
Test Frequency 1MHz
Inductance 2.2μH
Case Code (Imperial) 1210
Case Code (Metric) 3225
Current Rating 790mA
Shielding Unshielded
Current Rating (Amps) 790mA
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Series WE-LQ
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Weight 15.989131mg
Supplier Device Package 1210
Package / Case 1210 (3225 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
