744031330 image
Favorite
744031330 image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-TPC Nonstandard 0.150Lx0.150W 3.80mmx3.80mm 33muH
PDF
/
Buying Options
Total Price: USD $8.91
Unit Price: USD $8.91195
≥1 USD $8.91195
≥10 USD $7.31215
≥100 USD $7.08415
≥500 USD $6.8552
≥1000 USD $6.6272
Inventory: 1278
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 3816
Weight 102.993818mg
Material - Core Ferrite

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-TPC
Size / Dimension 0.150Lx0.150W 3.80mmx3.80mm
Tolerance ±30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 420mA
Shielding Shielded
Depth 3.8mm
Current Rating 420mA
Inductance 33μH
Test Frequency 100kHz
DC Resistance (DCR) 660mOhm Max
Max DC Current 420mA
Frequency - Self Resonant 25MHz
Inductance Frequency - Test 100kHz
Current - Saturation 320mA
Inductance Tolerance 30%
RMS Current (Irms) 420mA

Dimensions

Height 1.65mm
Height Seated (Max) 0.071 1.80mm
Length 3.8mm
Width 3.8mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
