IHLP3232DZER330M51

Vishay
RoHS
/
Package 3232
Category Inductors, Coils, Chokes / Fixed Inductors
Description 3232 33muH 20%
PDF
/
Buying Options
Total Price: USD $1.19
Unit Price: USD $1.188229
≥1 USD $1.188229
≥10 USD $1.120974
≥100 USD $1.057528
≥500 USD $0.997663
≥1000 USD $0.941186
Inventory: 1200
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Dimensions

Width 8.18mm
Length 8.1788mm
Height Seated (Max) 4.0132mm
Height 4.0132mm

Technical

Inductance-Nom (L) 33 μH
DC Resistance (DCR) - Parallel 159.43mOhm
Current - Saturation 3.2A
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application DC-DC CONVERTER
Frequency - Self Resonant 6.1MHz
Max DC Current 3.1A
Test Frequency 100kHz
Inductance 33 μH
Military Standard Not
Current Rating 3.1A
Reach Compliance Code unknown
Depth 8.26mm
Number of Functions 1
Shielding Shielded
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Min Operating Temperature -55°C
Max Operating Temperature 155°C
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Pbfree Code yes
JESD-609 Code e3
Tolerance 20%
Packaging Tape & Reel (TR)

Physical

Core Material COMPOSITE
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WRAPAROUND
Package / Case 3232
Mount Surface Mount
