IRF03ER101K
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
IRF Axial 0.170Diax0.385L 4.32mmx9.78mm 100muH
PDF
/
Inventory: 3091
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case Axial
Surface Mount NO
Terminal Shape WIRE
Material - Core Ferrite
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~105°C
Packaging Tape and Reel
Published 2012
Series IRF
Size / Dimension 0.170Diax0.385L 4.32mmx9.78mm
Tolerance ±10%
JESD-609 Code e2
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Copper (Sn99.3Cu0.7)
HTS Code 8504.50.80.00
Packing Method TR
Shielding Unshielded
Number of Functions 1
Construction Epoxy Coated
Current Rating 275mA
Military Standard Not
Lead Length 36.515mm
Lead Diameter 0.635 mm
Inductance 100μH
Test Frequency 2.5MHz
DC Resistance (DCR) 1.8Ohm Max
Max DC Current 275mA
Frequency - Self Resonant 9.5MHz
Inductor Application RF INDUCTOR
Q @ Freq 30 @ 2.5MHz
Quality Factor-Min (at L-nom) 30
Inductor Type GENERAL PURPOSE INDUCTOR
DC Current 275mA
Special Feature Q MEASURED AT 2.5MHZ
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
