IRF01BH8R2K

Vishay Dale
RoHS
RoHS RoHS compliant
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR ROHS3Compliant Obsolete WIRE fixed air core inductor -55C~105C 55MHz 550mOhm Max 8.2muH
PDF
/
Inventory: 5095
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mounting Type Through Hole
Package / Case Axial
Surface Mount NO
Terminal Shape WIRE
Material - Core Ferrite
Shape/Size Description TUBULAR PACKAGE

Technical

Operating Temperature -55°C~105°C
Packaging Bulk
Published 2016
Series IRF
Size / Dimension 0.120Diax0.260L 3.02mmx6.60mm
Tolerance ±10%
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
HTS Code 8504.50.80.00
Shielding Unshielded
Number of Functions 1
Construction Epoxy Coated
Lead Length 36.515mm
Lead Diameter 0.508 mm
Inductance 8.2μH
Test Frequency 7.9MHz
DC Resistance (DCR) 550mOhm Max
Max DC Current 425mA
Frequency - Self Resonant 55MHz
Inductor Application RF INDUCTOR
Q @ Freq 50 @ 7.9MHz
Quality Factor-Min (at L-nom) 50
Inductance Frequency - Test 7.9MHz
Inductor Type GENERAL PURPOSE INDUCTOR

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
