IHLP2525CZER3R3M8A
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
IHLP-2525CZ-8A Nonstandard 0.270Lx0.255W 6.86mmx6.47mm 3.3muH
PDF
/
Buying Options
Total Price: USD $0.99
Unit Price: USD $0.9944
≥1 USD $0.9944
≥10 USD $0.8404
≥100 USD $0.76384
≥500 USD $0.717904
≥1000 USD $0.59576
≥3000 USD $0.54993
Inventory: 1141
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~180°C
Packaging Tape & Reel (TR)
Published 2015
Series IHLP-2525CZ-8A
Size / Dimension 0.270Lx0.255W 6.86mmx6.47mm
Tolerance ±20%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Molded
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding YES
Number of Functions 1
Construction Rectangular
Current Rating 6.8A
Case Code (Metric) 6363
Case Code (Imperial) 2525
Inductance 3.3μH
Test Frequency 100kHz
DC Resistance (DCR) 28.4mOhm Max
Max DC Current 6.8A
Frequency - Self Resonant 28.3MHz
Inductor Application HIGH CURRENT INDUCTOR
Terminal Placement DUAL ENDED
Current - Saturation 8.3A
Case/Size Code 2726
Inductance Tolerance 20%
RMS Current (Irms) 6.8A
Dimensions
Height 3mm
Height Seated (Max) 0.118 3.00mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
