IHB4BV122K
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Ind High Current Filter 1.2mH 10% 1KHz 5.5A RDL Bulk
PDF
/
Inventory: 5579
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder
Technical
Operating Temperature -55°C~130°C
Packaging Bulk
Series IHB
Size / Dimension 1.600Dia 40.64mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Wirewound
Max Operating Temperature 130°C
Min Operating Temperature -55°C
Current Rating (Amps) 3.1A
Shielding Unshielded
Inductance 1.2mH
DC Resistance (DCR) 232mOhm Max
Max DC Current 5.5A
Lead/Base Style Radial
Inductance Frequency - Test 1kHz
Dimensions
Height 26.16mm
Height Seated (Max) 1.030 26.16mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
