HM61-101R0LFTR7
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RoHS Compliant Wirewound Discontinued 2009 Fixed Inductor -40C~155C 120MHz 15mOhm 1muH
PDF
/
Inventory: 5524
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Technical
Operating Temperature -40°C~155°C
Packaging Tape & Reel (TR)
Published 2009
Series HM61
Size / Dimension 0.189Lx0.165W 4.80mmx4.20mm
Tolerance ±10%
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Max Operating Temperature 155°C
Min Operating Temperature -40°C
Current Rating (Amps) 4A
Shielding Unshielded
Current Rating 4A
Inductance 1μH
Test Frequency 100kHz
DC Resistance (DCR) 15mOhm
Frequency - Self Resonant 120MHz
Inductance Frequency - Test 100kHz
Dimensions
Height 5.6896mm
Height Seated (Max) 0.185 4.70mm
Length 8.509mm
Width 6.35mm
Compliance
RoHS Status RoHS Compliant
