892NAS-100MP3
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant Lead Free WRAPAROUND Fixed Inductor 100kHz 22.5mOhm 10muH 20%
PDF
/
Inventory: 1882
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Core Material Ferrite
Technical
Packaging Bulk
Series #892N
Tolerance 20%
Number of Terminations 2
ECCN Code EAR99
HTS Code 8504.50.80.00
Packing Method TR
Shielding Unshielded
Number of Functions 1
Depth 12.3mm
Construction Magnetically Shielded
Current Rating 4.2A
Inductance 10 μH
Test Frequency 100kHz
Current 1.01A
Max DC Current 4.2A
Inductor Application HIGH CURRENT INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Case/Size Code 4848
DC Resistance (DCR) - Parallel 22.5mOhm
Inductance-Nom (L) 10 μH
Special Feature LOW PROFILE
Dimensions
Height 4.5mm
Height Seated (Max) 4.4958mm
Length 12.2936mm
Width 12.2936mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
