3632A682LT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
3632Sigma Inductors Nonstandard 0.413Lx0.374W 10.50mmx9.50mm 6.8mH
PDF
/
Inventory: 3043
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.248 6.30mm
Technical
Rated Current-Max 0.09A
Inductor Type GENERAL PURPOSE INDUCTOR
Inductance Frequency - Test 1kHz
Quality Factor-Min (at L-nom) 100
Q @ Freq 100 @ 252kHz
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 900kHz
DC Resistance (DCR) 24Ohm Max
Inductance 6.8mH
Number of Functions 1
Shielding Shielded
Current Rating (Amps) 90mA
HTS Code 8504.50.80.00
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±15%
Size / Dimension 0.413Lx0.374W 10.50mmx9.50mm
Series 3632, Sigma Inductors
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -25°C~105°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape GULL WING
Surface Mount YES
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 37 Weeks
