3631B100MT
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
3631Sigma Inductors Nonstandard 0.500Lx0.500W 12.70mmx12.70mm 10muH
PDF
/
Inventory: 2245
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.236 6.00mm
Technical
Rated Current-Max 3.3A
Case/Size Code 5050
Inductor Type GENERAL PURPOSE INDUCTOR
Inductance Frequency - Test 1kHz
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
DC Resistance (DCR) 35mOhm Max
Inductance 10μH
Construction Chip
Number of Functions 1
Shielding Shielded
Packing Method TR
Current Rating (Amps) 3.3A
HTS Code 8504.50.80.00
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±20%
Size / Dimension 0.500Lx0.500W 12.70mmx12.70mm
Series 3631, Sigma Inductors
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -25°C~105°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape ONE SURFACE
Surface Mount YES
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 37 Weeks
