MGDU1-00003
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RoHS Compliant Lead Free Tape & Reel (TR) Surface Mount fixed air core inductor 85C 100kHz 70mOhm 2.2muH
PDF
/
Inventory: 980
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Technical
Packaging Tape & Reel (TR)
Tolerance 20%
Resistance 70mOhm
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Composition Wirewound
Shielding Unshielded
Depth 4.5mm
Current Rating 2.4A
Inductance 2.2 μH
ELV Compliant
Test Frequency 100kHz
Max DC Current 2.4A
Current - Saturation 2.3A
DC Resistance (DCR) - Parallel 70mOhm
Dimensions
Height 2.92mm
Height Seated (Max) 2.921mm
Length 6.604mm
Width 4.4958mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
