DU6629-681M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Contains Lead 8504.50.80.00 fixed air core inductor 85C 100kHz 9.2Ohm 680muH
PDF
/
Inventory: 7665
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Core Material AMORPHOUS MAGNETIC
Technical
Packaging Tape & Reel (TR)
Series DU6629
Tolerance 20%
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8504.50.80.00
Packing Method TR
Shielding Unshielded
Current Rating 120mA
Inductance 680 μH
Test Frequency 100kHz
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 100mA
Case/Size Code 2618
DC Resistance (DCR) - Parallel 9.2Ohm
Rated Current-Max 0.1A
Inductance-Nom (L) 680 μH
Dimensions
Height Seated (Max) 2.921mm
Length 6.604mm
Width 4.4958mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
