DU6629-150M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Contains Lead 8504.50.80.00 Tape & Reel (TR) Fixed Inductor 85C 100kHz 230mOhm 15muH
PDF
/
Inventory: 7033
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Technical
Packaging Tape & Reel (TR)
Tolerance 20%
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8504.50.80.00
Shielding Unshielded
Current Rating 1.2A
Inductance 15 μH
Test Frequency 100kHz
Current - Saturation 900mA
DC Resistance (DCR) - Parallel 230mOhm
Dimensions
Height Seated (Max) 2.921mm
Length 6.604mm
Width 4.4958mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
