DU1971-2R2M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Contains Lead 8504.50.80.00 fixed air core inductor 85C 100kHz 14mOhm 2.2muH
PDF
/
Inventory: 1611
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case Nonstandard
Core Material AMORPHOUS MAGNETIC
Technical
Packaging Tape & Reel (TR)
Series DU1971
Tolerance 20%
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8504.50.80.00
Packing Method TR
Shielding Unshielded
Current Rating 7.1A
Inductance 2.2 μH
Test Frequency 100kHz
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 16A
Case/Size Code 7360
DC Resistance (DCR) - Parallel 14mOhm
Inductance-Nom (L) 2.2 μH
Dimensions
Height Seated (Max) 7.3914mm
Length 18.542mm
Width 15.24mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
