DU1311-680M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Contains Lead 8504.50.80.00 fixed air core inductor 85C 100kHz 170mOhm 68muH
PDF
/
Inventory: 9878
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 9.398mm
Length 12.954mm
Height Seated (Max) 11.43mm
Technical
Inductance-Nom (L) 68 μH
Rated Current-Max 3A
DC Resistance (DCR) - Parallel 170mOhm
Case/Size Code 5137
Current - Saturation 3A
Inductor Type GENERAL PURPOSE INDUCTOR
Test Frequency 100kHz
Inductance 68 μH
Current Rating 1.2A
Shielding Unshielded
Packing Method TR
HTS Code 8504.50.80.00
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Tolerance 20%
Series DU1311
Packaging Tape & Reel (TR)
Physical
Core Material AMORPHOUS MAGNETIC
Package / Case Nonstandard
Mount Surface Mount
