DS1351-1R0M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Contains Lead Cut Tape (CT) Surface Mount Fixed Inductor 85C 100kHz 21mOhm 1muH
PDF
/
Inventory: 5164
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 10.1092mm
Length 12.954mm
Height Seated (Max) 5.1054mm
Height 5.1054mm
Technical
DC Resistance (DCR) - Parallel 21mOhm
Current - Saturation 5.8A
Test Frequency 100kHz
Inductance 1 μH
Current Rating 5A
Shielding Shielded
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Tolerance 20%
Packaging Cut Tape (CT)
Physical
Package / Case Nonstandard
Mount Surface Mount
