DQ7534-120M

TE Connectivity
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Contains Lead WRAPAROUND fixed air core inductor 85C 100kHz 98mOhm 12muH
PDF
/
Inventory: 1449
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 1.52A
DC Resistance (DCR) - Parallel 98mOhm
Inductance-Nom (L) 12 μH
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Test Frequency 100kHz
Inductance 12 μH
Current Rating 1.52A
Number of Functions 1
Shielding Shielded
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Tolerance 20%
Packaging Tape & Reel (TR)

Dimensions

Height Seated (Max) 3.4036mm
Width 7.493mm
Length 7.493mm

Physical

Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mount Surface Mount

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
