B82498F3471J001
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
EPCOS B82498F3471J001 Surface Mount High Frequency Inductor, 470 nH, 190 mA, 0805 [2012 Metric], Wirewound, 1.9 ohm
PDF
/
Inventory: 2736
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.055 1.40mm
Technical
Inductance Frequency - Test 50MHz
Q @ Freq 30 @ 100MHz
Frequency - Self Resonant 650MHz
DC Resistance (DCR) 1.9Ohm Max
Inductance 470nH
Shielding Unshielded
Current Rating (Amps) 190mA
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Size / Dimension 0.091Lx0.067W 2.30mmx1.70mm
Series SIMID
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material - Core Ceramic
Supplier Device Package 0805 (2012 Metric)
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
