B82144B1475J000
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RF Choke Drum Core 4.7mH 5% 100KHz 60Q-Factor Ferrite 120mA 21Ohm DCR RDL T/R
PDF
/
Buying Options
Total Price: USD $0.49
Unit Price: USD $0.4928
≥1 USD $0.4928
≥10 USD $0.41888
≥100 USD $0.384384
≥500 USD $0.34936
≥1000 USD $0.310904
≥3000 USD $0.293427
Inventory: 3035
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.571 14.50mm
Technical
Inductance Frequency - Test 100kHz
Q @ Freq 60 @ 252kHz
Frequency - Self Resonant 1.1MHz
DC Resistance (DCR) 21Ohm Max
Inductance 4.7mH
Shielding Unshielded
Current Rating (Amps) 120mA
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Size / Dimension 0.256Dia 6.50mm
Series LBC
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material - Core Ferrite
Package / Case Radial, Vertical Cylinder
Mounting Type Through Hole
Supply Chain
Factory Lead Time 8 Weeks
