T1008-R33G
RoHS
/
Package 1008 (2520 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RoHS Compliant Wirewound Obsolete Lead Free Fixed Inductor 570MHz 450mOhm Max 330nH ±2%
PDF
/
Inventory: 6306
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1008 (2520 Metric)
Technical
Packaging Tape & Reel (TR)
Published 2002
Series T1008
Size / Dimension 0.106Lx0.098W 2.70mmx2.50mm
Tolerance ±2%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Shielding Unshielded
Current Rating 450mA
Inductance 330nH
Test Frequency 25MHz
DC Resistance (DCR) 450mOhm Max
Frequency - Self Resonant 570MHz
Q @ Freq 40 @ 100MHz
Inductance Frequency - Test 25MHz
Dimensions
Height Seated (Max) 0.089 2.25mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
