DPV-1.0-330
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 330UH 1A 193 MOHM TH
PDF
/
Buying Options
Total Price: USD $35.77
Unit Price: USD $35.7675
≥1 USD $35.7675
≥10 USD $29.3474
≥100 USD $28.43065
≥500 USD $27.5139
≥1000 USD $26.5962
Inventory: 1116
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.984 25.00mm
Technical
Inductance Frequency - Test 10kHz
DC Resistance (DCR) 193mOhm Max
Inductance 330μH
Shielding Unshielded
Current Rating (Amps) 1A
Type Toroidal
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.906Lx0.610W 23.00mmx15.50mm
Series DP
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Package / Case Radial, Vertical
Mounting Type Through Hole
Supply Chain
Factory Lead Time 18 Weeks
