CAL45VB150K
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
CA L Type Axial 0.173Diax0.315L 4.40mmx8.00mm 15muH
PDF
/
Inventory: 1840
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Shape/Size Description TUBULAR PACKAGE
Core Material FERRITE
Technical
Operating Temperature -25°C~105°C
Packaging Tape & Box (TB)
Published 2015
Series CA, L Type
Size / Dimension 0.173Diax0.315L 4.40mmx8.00mm
Tolerance ±10%
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Packing Method Ammo Pack
Shielding Unshielded
Number of Functions 1
Construction Cylindrical
Current Rating 1.4A
Lead Diameter 0.65 mm
Inductance 15μH
Test Frequency 2.52MHz
DC Resistance (DCR) 190mOhm Max
Max DC Current 1.4A
Inductor Application HIGH CURRENT INDUCTOR
Halogen Free Halogen Free
Q Factor 40
Self Resonant Frequency 25MHz
Dimensions
Height Seated (Max) 13.9954mm
Compliance
RoHS Status RoHS Compliant
