CAL45VB120K
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
CA L Type Axial 0.173Diax0.315L 4.40mmx8.00mm 12muH
PDF
/
Inventory: 1701
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 13.9954mm
Technical
Self Resonant Frequency 25MHz
Q Factor 40
Current - Saturation 1.6A
Halogen Free Halogen Free
Inductor Application HIGH CURRENT INDUCTOR
Max DC Current 1.6A
DC Resistance (DCR) 170mOhm Max
Test Frequency 2.52MHz
Inductance 12μH
Lead Diameter 0.65 mm
Current Rating 1.45A
Construction Cylindrical
Number of Functions 1
Shielding Unshielded
Packing Method Ammo Pack
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Tolerance ±10%
Size / Dimension 0.173Diax0.315L 4.40mmx8.00mm
Series CA, L Type
Published 2015
Packaging Tape & Box (TB)
Operating Temperature -25°C~105°C
Physical
Core Material FERRITE
Shape/Size Description TUBULAR PACKAGE
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
