CAL45VB102K
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
CA L Type Axial 0.173Diax0.315L 4.40mmx8.00mm 1mH
PDF
/
Inventory: 9938
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 13.9954mm
Diameter 4.4mm
Technical
Self Resonant Frequency 2.5MHz
Q Factor 80
Current - Saturation 190mA
Halogen Free Halogen Free
Inductor Application HIGH CURRENT INDUCTOR
Max DC Current 190mA
DC Resistance (DCR) 13.2Ohm Max
Test Frequency 252kHz
Inductance 1mH
Current Rating 170mA
Construction Cylindrical
Number of Functions 1
Shielding Unshielded
Packing Method Ammo Pack
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Tolerance ±10%
Size / Dimension 0.173Diax0.315L 4.40mmx8.00mm
Series CA, L Type
Published 2015
Packaging Tape & Box (TB)
Operating Temperature -25°C~105°C
Physical
Core Material FERRITE
Shape/Size Description TUBULAR PACKAGE
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
