RCH875NP-221K
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RCH-875 Radial Vertical Cylinder (Open) 0.307Dia 7.80mm 220muH
PDF
/
Inventory: 1355
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder (Open)
Weight 1.130012g
Material - Core Ferrite
Shape/Size Description CYLINDRICAL PACKAGE
Technical
Operating Temperature -40°C~100°C
Packaging Tape & Reel (TR)
Published 2012
Series RCH-875
Size / Dimension 0.307Dia 7.80mm
Tolerance ±10%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Through Hole
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Current Rating 380mA
Lead Diameter 0.7 mm
Inductance 220μH
Test Frequency 1kHz
DC Resistance (DCR) 630mOhm Max
Max DC Current 570mA
Lead/Base Style Radial
Dimensions
Height 7.5mm
Height Seated (Max) 0.295 7.50mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
