RoHS
RoHS RoHS compliant
Package Radial, Vertical Cylinder (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Wirewound Active Radial Fixed Inductor -40C~100C 13MHz 190mOhm Max 39muH
PDF
/
Inventory: 1831
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder (Open)
Weight 700.006425mg
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Operating Temperature -40°C~100°C
Packaging Tape & Reel (TR)
Published 2012
Series RCH-664
Size / Dimension 0.236Dia 6.00mm
Tolerance ±10%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Current Rating 950mA
Lead Length 4mm
Lead Spacing 4mm
Lead Diameter 0.5 mm
Inductance 39μH
Test Frequency 2.52MHz
DC Resistance (DCR) 190mOhm Max
Max DC Current 950mA
Inductor Application POWER INDUCTOR
Lead/Base Style Radial
Self Resonant Frequency 13MHz

Dimensions

Height 6.5mm
Height Seated (Max) 0.256 6.50mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
