CMD4D11NP-470MC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR ROHS3Compliant Active WRAPAROUND fixed air core inductor 100kHz 2.843Ohm Max 47muH ±20%
PDF
/
Inventory: 8973
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.047 1.20mm
Height 1.2mm
Technical
Case/Size Code 1716
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Max DC Current 180mA
DC Resistance (DCR) 2.843Ohm Max
Test Frequency 100kHz
Inductance 47μH
Current Rating 180mA
Depth 4.4mm
Number of Functions 1
Shielding NO
HTS Code 8504.50.80.00
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±20%
Size / Dimension 0.169Lx0.161W 4.30mmx4.10mm
Series CMD4D11
Published 2010
Packaging Tape & Reel (TR)
Physical
Core Material Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
