CMD4D11NP-220MC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR ROHS3Compliant Active WRAPAROUND fixed air core inductor 100kHz 1.066Ohm Max 22muH ±20%
PDF
/
Inventory: 6378
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Core Material Ferrite
Technical
Packaging Tape & Reel (TR)
Published 2010
Series CMD4D11
Size / Dimension 0.169Lx0.161W 4.30mmx4.10mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Depth 4.4mm
Current Rating 300mA
Inductance 22μH
Test Frequency 100kHz
DC Resistance (DCR) 1.066Ohm Max
Max DC Current 300mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Type GENERAL PURPOSE INDUCTOR
Case/Size Code 1716
Dimensions
Height 1.2mm
Height Seated (Max) 0.047 1.20mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
