RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR ROHS3Compliant Active FLAT Fixed Inductor 100kHz 174mOhm Max 3.3muH ±20%
PDF
/
Inventory: 7380
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape FLAT
Shape/Size Description RECTANGULAR PACKAGE
Core Material Ferrite

Technical

Packaging Tape & Reel (TR)
Published 2010
Series CMD4D06
Size / Dimension 0.169Lx0.161W 4.30mmx4.10mm
Tolerance ±20%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Depth 5.8mm
Current Rating 770mA
Inductance 3.3μH
Test Frequency 100kHz
DC Resistance (DCR) 174mOhm Max
Max DC Current 770mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Type GENERAL PURPOSE INDUCTOR
Case/Size Code 1714

Dimensions

Height 800μm
Height Seated (Max) 0.031 0.80mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
