CLS4D23B-170NC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR ROHS3Compliant Active WRAPAROUND fixed air core inductor -40C~105C 1MHz 385mOhm Max 17muH
PDF
/
Inventory: 9326
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Published 2009
Series CLS4D23B
Size / Dimension 0.197Lx0.189W 5.00mmx4.80mm
Tolerance ±30%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 2
Reach Compliance Code unknown
Current Rating 950mA
Inductance 17μH
Test Frequency 1MHz
DC Resistance (DCR) 385mOhm Max
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Inductance Frequency - Test 1MHz
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 560mA
Rated Current-Max 0.95A
Special Feature PARALLEL CONNECTED
Dimensions
Height Seated (Max) 0.098 2.50mm
Compliance
RoHS Status ROHS3 Compliant
