CDRH105RNP-121NC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
CDRH105R Nonstandard 0.402Lx0.394W 10.20mmx10.00mm 120muH
PDF
/
Inventory: 3354
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Max DC Current 3.8A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 1.28A
Case/Size Code 4039
DC Resistance (DCR) 303mOhm Max
Test Frequency 100kHz
Inductance 120μH
Current Rating 1.18A
Depth 10.3mm
Number of Functions 1
Shielding YES
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Tolerance ±30%
Size / Dimension 0.402Lx0.394W 10.20mmx10.00mm
Series CDRH105R
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~100°C
Dimensions
Height 5.1mm
Height Seated (Max) 0.201 5.10mm
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 15 Weeks
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
