CDH2D09SNP-100MC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
CDH2D09S Nonstandard 0.094Lx0.094W 2.40mmx2.40mm 10muH
PDF
/
Inventory: 8321
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~105°C
Packaging Tape & Reel (TR)
Published 2008
Series CDH2D09S
Size / Dimension 0.094Lx0.094W 2.40mmx2.40mm
Tolerance ±20%
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Shielding NO
Number of Functions 1
Depth 2.55mm
Current Rating 360mA
Inductance 10μH
Test Frequency 100kHz
DC Resistance (DCR) 830mOhm
Max DC Current 360mA
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 280mA
Dimensions
Height 1mm
Height Seated (Max) 0.039 1.00mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
