SCRH64B-271
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 270UH 260MA 2.37 OHM
PDF
/
Inventory: 9542
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2009
Series SCRH64B
Size / Dimension 0.256Lx0.252W 6.50mmx6.40mm
Tolerance ±20%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Current Rating (Amps) 260mA
Shielding Shielded
Current Rating 260mA
Inductance 270μH
Test Frequency 1kHz
DC Resistance (DCR) 2.37Ohm Max
Inductance Frequency - Test 1kHz
Current - Saturation 260mA
Dimensions
Height Seated (Max) 0.205 5.20mm
Length 6.5024mm
Width 6.4008mm
Compliance
RoHS Status ROHS3 Compliant
